Routine Service and Maintenance
4.15
Weekly Maintenance Procedures
Do the following procedures weekly or every 50 operating hours:
1. Do all Daily maintenance procedures
2. Check the battery (Item 1, Figure 4–16) and cable connections (Items 2 and 3,
Figure 4–16) for signs of leaking, corrosion or damage. (Some items have been
removed for clarity.)
NOTE: The electrical system on this machine is a NEGATIVE ground system.
Figure 4-16 Battery and Cable Connections
1
3
2
