BOXER 700HDX - Section 2 - Operating Controls; Component Locations; Left Front View

2.1
Section 2 - Operating Controls
Component Locations
NOTE: FRONT PANEL REMOVED FOR CLARITY.
Left Front View
Item No. Description
1 Attachment mounting plate
2 Boom
3 Joysticks
4 Manual Holder
5 Fuel Fill Cap
6 Lift Cylinder
7 Fuel Tank
8 Right Track Assembly
9 Lift Cylinder Safety Lock
10 Hydraulic Level Check
1
2
4
5
7
8
9
10
6
3
