BOXER 600HD - Page 40

Pre Start Inspection and Operation
3.17
Forward Travel Reverse Travel
Push left joystick
forward to travel
straight forward.
The farther this is
moved, the faster
the machine will
travel. See Figure
3–16.
Figure 3-16
Forward Travel
Pull left joystick
backwards to
travel straight
backwards. The
farther this is
moved, the faster
the machine will
travel. See Figure
3–17.
Figure 3-17
Reverse Travel
Right Turn During Forward Travel Left Turn During Forward Travel
To turn to the
right, move the
left joystick
forward and
slightly to the
right. The farther
forward and
slightly right the
joystick is moved,
the faster the right
turn will be made.
See
Figure 3–18.
Figure 3-18 Right
Hand Turn
in Forward
To turn to the
left, move the left
joystick forward
and slightly to the
left. The farther
forward and
slightly left the
joystick is moved,
the faster the left
turn will be made.
See
Figure 3–19.
Figure 3-19 Left
Hand Turn in
Forward
