Left Handle Bar Switches
A. Dipper Switch : When headlight is ON, High or
Low beam can be selected using the dipper
switch. Hi beam indicator light located on
Speedo console will glow when high beam is
selected.
: High Beam : Low beam
B. Turn Signal Switch : When the turn signal knob
is turned to Left side ( ) or Right side ( ) the
respective indicator will start blinking. To Put off
the side indicator selected, just press the knob
‘B’ in the center & release it.
C. Horn Button : ( ) To operate the horn press
button ‘C’.
Control Switches
A
B
C
8
E
D
Right Handle Bar Switches
D. Head Light Switch : It has 2 positions.
: All lamps 'OFF’.
: While engine running, Head lamp,
Tail lamp & Meter lamps are ‘ON’.
E. Starter Button : Electric starter operates only
when the vehicle is in neutral position. Self start is not
possible in gear engaged mode.
