BOXER BM 125 - Technical Specifications

Engine : 4 stroke, single cylinder
Natural air cooled,
Spark ignition
Bore x Stroke : 54.0 mm x 54.4 mm
Eng. Displacement : 124.6 cc
Compression Ratio : 9.5 + 0.5 : 1
Idling Speed : 1400 rpm + 100
Max. Net Power : 9 PS (6.62kw) @ 7500 rpm
Max. Net Torque : 10.8 Nm @ 5500 rpm
Ignition System : AC
Spark Plug (1 Nos) : Make- CHAMPION
(Gap:- 0.7 – 0.8 mm)
Identification- RG4HC
Spark Plug Gap : 0.7~0.8 mm
Lubrication : Wet sump, Forced.
Transmission : 4 s p e e d c o n s t a n t
mesh.
Front Brake : Mech. expanding shoe
110 mm dia. Drum
Rear Brake : Mech. expanding shoe
130 mm dia. Drum
Fuel Tank Capacity :
Full : 11 liters
Reserve : 2.5 liters
Usable : 1 liters
Dimensions :
Length : 2005 mm
Width : 704 mm
Height : 1073 mm
Wheel base : 1295 mm
Ground clearance : 803 mm
1
Technical Specifications
