MULCHING MOWER MASTER SERIES | User manual February 2021
11. Greasing the machine:
To ensure smooth functioning, it is necessary to lubricate the machine with grease. Figures 31 and 32 show the
grease nipples where the grease gun must be attached to the machine.
Figure 33 shows one side of the power take-off with grease nipple. Please correctly lubricate both sides of the power
take-off.
Figure 34 shows one of the four grease nipples on the hydraulic lateral shifter. Here it can be seen why the grease
nipples must be aligned correctly (also see Figure 11). Lubricate all 4 grease nipples using the grease gun.
Fig. 31 Grease nipple in travel direction left Fig. 32 Grease nipple in travel direction right
Fig. 33 Grease nipple on the power take-off Fig. 34 Grease nipple on the hydraulic lateral shifter
(one of four)
