Page 35/42
February 2021MULCHING MOWER MASTER SERIES | User manual
10. EXPLODED-VIEW DRAWING
10.1 Master
MASTER
No. Article no. Part no. Name Quantity Remark
1 801680014 EFGCM120.014B Mount 1
2 802480066 EFAG140.014 Lower link bolt 2 EFGCHMZ105-175
2 (1) 702480065 EFAG140.114A Connecting sleeve 2 EFGCHMZ200-220
3 701600028 EFGCH120.103 Cover 4
4 509010017 GB1153-M6X45° Grease nipple 4
