Page 36/42
MULCHING MOWER MASTER SERIES | User manual February 2021
5 501011128 GB5783-M12x40 Screw 16
6 801680009 EFGCHM120.013 Lateral shifter frame 1
7 501011121 GB5783-M10x70 Screw 4
8 503010046 GB6170-M10 Nut 4
9 701600030 EFGCH120.104
(1200-1700)(L=1218)
Guide rail
2 EFGCHM105-175
9 (1) 701600031 EFGCH120.104A
(L=1342)
Guide rail
2 EFGCHM200-220
10 801240019 EFGC120.013 Left skid 1
11 700940005 EF100.00.123 Protective plate bar 1 EFGCHMZ105
11 (1) 700950005 EF110.00.123 Protective plate bar (115) 1 EFGCHMZ115
11 (2) 700960009 EF120.00.123 Protective plate bar (125) 1 EFGCHMZ125
11 (3) 700970005 EF130.00.123 Protective plate bar (135) 1 EFGCHMZ135
11 (4) 700980005 EF140.00.123 Protective plate bar (145) 1 EFGCHMZ145
11 (5) 700990019 EF150.00.123 Protective plate bar (155) 1 EFGCHMZ155
11 (6) 701000005 EF160.00.123 Protective plate bar (165) 1 EFGCHMZ165
11 (7) 701010005 EF170.00.123 Protective plate bar (175) 1 EFGCHMZ175
11 (8) 701010006 EF200.00.123 Protective plate bar (200) 1 EFGCHMZ200
11 (9) 701010007 EF220.00.123 Protective plate bar (220) 1 EFGCHMZ220
12 508011473 GB879.1-4x25 Cylindrical pin 2
13 700920108 EF100.00.122 Protective plate 9
14 503010314 GB6184-M18 Lock nut 3
15 506010060 GB97.1-18 Washer 2
16 701600026 EFGCH120.101 Distance sleeve 1
17 516010004 TDQ-12 Washer 4
18 501014706 GB3541-M12X1.25 Flat head anchor bolt 2
19 701600001 EFGCH120.011 (1500) Hydraulic line 1
20 705380114 RK120.401 Adapter 2
21 703820055 QUICK-COUPLING G1/2-G G1/2 quick coupling 2
22 701600002 EFGCH120.012 Lateral shifter ram 1 EFGCHMZ105-175
22 (1) 701600004 EFGCH120.012B Lateral shifter ram 1 EFGCHMZ200-220
23 700920107 EF100.00.121 Narrow protective plate 2
24 801680007 EFGCHM120.012 Right flat bar 1
25 503010311 GB6184-M12 Lock nut 24
26 801240022 EFGC120.014 Right skid 1
27 506010057 GB97.1-12 Washer 24
28 501011126 GB5783-M12x30 Screw M12x30 17
29 501011565 GB5785-M16x1.5x90 Screw M16x1.5x90 24
30 701240009 EFGC120.104 Flail 48
31 701240008 EFGC120.103 Distance sleeve 48
32 503010313 GB6184-M16 Lock nut 24
MASTER
No. Article no. Part no. Name Quantity Remark
