February 2021MULCHING MOWER MASTER SERIES | User manual
33 801140010 EFG100.013A Flail shaft (105) 1 EFGCHMZ105
33 (1) 801150010 EFG110.013A Flail shaft (115) 1 EFGCHMZ115
33 (2) 801160038 EFG120.013A Flail shaft (125) 1 EFGCHMZ125
33 (3) 801170010 EFG130.013A Flail shaft (135) 1 EFGCHMZ135
33 (4) 801180010 EFG140.013A Flail shaft (145) 1 EFGCHMZ145
33 (5) 801190010 EFG150.013A Flail shaft (155) 1 EFGCHMZ155
33 (6) 801200010 EFG160.013A Flail shaft (165) 1 EFGCHMZ165
33 (7) 801210010 EFG170.013A Flail shaft (175) 1 EFGCHMZ175
33 (8) 801130019 EFG200.013A-G2 Flail shaft (200) 1 EFGCHMZ200
33 (9) 802080085 EFG220.013A-G2 Flail shaft (220) 1 EFGCHMZ220
34 511040033 UC207-Z Bearing UC207 2
35 506030037 GB93-12 Spring washer 13
36 701600005 EFGCH120.011A Hydraulic hose (1900) 1
37 510020417 GB13871-FB-55x80x8 FB sealing ring 1 EFGCHMZ105-175
37 (1) 510020397 CFW-60X85X8 FB sealing ring 1 EFGCHMZ200-220
38 506010056 GB97.1-10 Washer 15
39 503010310 GB6184-M10 Lock nut 4
40 509010008 GB1152-M8x1 Grease nipple 4
41 515010001 REACH04-35X60 Cover lock 2
42 701160006 EFG120.105A Small pulley (three-track) 1 EFGCHM105-175
42 (1) 701160034 EFG120.105B Small pulley EFGCHM200-220
43 514010001 17X991 V-belt 3
44 705380014 RK120.109A (EFG135-175)(L=48) Cover 1 EFGCHMZ105-175
44 (1) 702080005 G2-150.105 Cover 1 EFGCHMZ200-220
45 701160033 EFG120.103 Small plate 1
46 701240046 EFGC120.138 Lower cover 1
47 501030185 GB70.3-M8x25 Allen screw 10
48 701250006 EFGC120.111
Large belt cover
(three-track)
1 EFGCHMZ105-175
48 (1) 706160004 EFGC200.111 Large belt cover 1 EFGCHMZ200-220
49 701160007 EFG120.106A Large pulley (three-track) 1 EFGCHMZ105-220
49 (1) 701160040 EFG120.106B Large pulley EFGCHMZ200-220
50 501011141 GB5783-M14x35 Screw M14x35 2
51 506010058 GB97.1-14 Washer 2
52 503010312 GB6184-M14 Lock nut 2
53 701240007 EFGC120.102A Pressure plate 1
54 501011905 GB5786-M16x1.5x50 Screw M16x1.5x50 1
55 503010137 GB6173-M16x1.5 Nut M16x1.5 1
56 801160001 EFG120.017
Right mounting, trailing
roller
1
57 801140004 EFG100.012 Trailing roller (105) 1 EFGCHMZ105
MASTER
No. Article no. Part no. Name Quantity Remark
