Page 21/42
February 2021MULCHING MOWER MASTER SERIES | User manual
10. Fill operating resources:
The transmission (Fig. 29) and drive shaft (Fig.30) must be supplied with sufficient transmission oil.
Unscrew the filler plug and inspection plug and remove them.
Then fill the transmission and drivetrain with oil until the oil can be seen at the inspection port.
We recommend SAE 80W90 transmission oil.
Attention: The mulcher must be horizontal to guarantee optimal filling.
Fig. 29 Transmission Fig. 30 Drive shaft with inspection port
and filling port
