9. Inspect pulleys for secure seating
Please ensure that the eight Allen screws on the pulleys are tightened and correctly connected to the drive shaft
(Figure 27) and the flail shaft (Figure 28).
Fig. 27 Upper pulley mounting Fig. 28 Lower pulley mounting
