Page 24/42
MULCHING MOWER MASTER SERIES | User manual February 2021
13. Fit power take-off guard:
Attach the guard to the transmission as shown in Figure 38 using the 4 screws, 4 spring washers and 4 washers.
Fig. 38 Power take-off guard Fig. 39 Reversible bolt with retaining pin
Fig. 40 Fitted reversible bolt with retaining pin
