Boya BOYALINK - Transmitter & Receiver Specifications; Technical Performance Specifications; Operational and Environmental Specs

Specications
Transmitter & Receiver
Transmission Type
2.4GHz digital frequency
Modulation
Digital modulation
Polar Pattern
Omnidirectional
Antenna
TX: Ceramic antenna, RX: pcb antenna
Operating Range (Without
Obstacle)
Up to 60m
Distortion
<
0.01%
Frequency Response
20Hz-20kHz
Sampling Rate
48kHz
Bit Rate
16bit
Signal-to-Noise Ratio
>85dB
Audio Input
TX: In-built microphone capsule
Audio Output
RX: 3.5mm TRS analog output, USB-C and iOS Lightning
digital output
Battery Voltage/ Capacity
TX: 3.7V/95mAh RX: 3.7V/120mAh
Power Requirements
In-built lithium-ion battery/ Charging contacts/
USB-C charging port
In-built Battery Life
TX: Approx. 10 hours
RX: Approx. 6 hours
Weight
TX: 12g;
RX: 15g (with an adapter)
Dimensions
TX: 59x16.2x12.8 mm; RX: 61x18.2x12.8 mm
Operating Temperature
0°C to +50°C
Storage Temperature
-10°C to +50°C
11
