Fastener Torque Values
FASTNER TYPE TORQUE VALUE (N-m, kgf-m, lb-ft)
5mm hex bolt and nut 6 Nm, .62 kgf-m , 4.5 lb-ft
6mm hex bolt and nut 10 Nm, 1.04 kgf-m, 7.5 lb-ft
8mm hex bolt and nut 25 Nm, 2.49 kgf-m, 18 lb-ft
10mm hex bolt and nut 50 Nm, 5.12 kgf-m, 37 lb-ft
12mm hex bolt and nut 85 Nm, 8.71 kgf-m, 63 lb-ft
5mm screw 6 Nm, .62 kgf-m , 4.5 lb-ft
6mm screw 10 Nm, 1.04 kgf-m, 7.5 lb-ft
8mm screw 25 Nm, 2.49 kgf-m, 18 lb-ft
Fig .1
