Engine
Displacement 196cc
Starting Manual/Electric (if equipped)
Spark Plug Type NGK BPR5ES
Cooling Air cooled
Engine Oil Capacity 600 ml (.63qt.)
5w-30 Full Synthetic
Number of Cylinder Single
Engine type 4-stroke
Horse Power 14hp/6000rpm
Torque 15 ft-lb
Top Speed 40km/h (25mph)
Battery (if equipped)
Type 12V Li-Po
Operating temperature range: -20C to +55C
Storage conditions: -5C to +35C, and less than
75% relative humidity
Transmission
Linked dual continuously variable belt
transmission.
Suspension
Type 6 Hydraulic shocks
Braking
Hydraulic Disk
Dimensions and Weights
Length:
Handle down 1150mm (45 in.)
Handle up 1321mm (52 in.)
Width 678mm (27 in.)
Height:
Handle down 584mm (23 in.)
Handle up 1270mm (50 in.)
Vehicle Wt. 111kg (245lbs)
Weight Cap. 113kg (250lbs)
Fuel
Gas Tank Capacity 3.78L (1 gal.)
Fuel type
Use premium high-octane fuel due to the
high compression ratio. Use 91 on the AKI
scale (USA) or 95 on the RON scale (rest
of world).
SPECIFICATIONS
Noise
The A-weighted emission sound pressure
level at operating station: 82 dB(A) with
uncertainty 3 dB(A).
The A-weighted sound power level emitted
by the DTV: 98 dB(A) with uncertainty 3
dB(A).
Vibration
The vibration on handles does not exceed
2.5m/s2.
Standards
This product is in conformity with the
following European standards:
• EC Machinery Directive (206/42/EC)
• EC EMC Directive (2004/108/EC)
• Applied Harmonized Standards: EN
ISO 12100
• CE AOC (attestation of compliance)
#12 12 82909 001
39
