Bpt LVC/01 User Manual

3
A
B
LC-01 LVC-01
Wall mounting
Using the Allen screwdriver remove the cover 󱭇. With the wall plugs
provided  x the entry panel at the desired height 󱭇 respecting the
positioning of the lens of the surveillance camera 󱭈.
Push through pipe 󱭇, take o the terminal board cover 󱭇 and
make the connections. Put back on the terminal board covers and assemble
the front cover.






PP
PP


PP
PP
PP
PP
99
30
207
135
3.5
6.5
243
H= 165 cm
(RECOMMENDED
HEIGHT)
KIT FREE_LC-LVC 24810470 25-11-14_EN
