the indications illustrated in figure 7.
• Make the electric connections to
the terminal block of the housing
as illustrated in the diagrams in
figure 12A or 12B.
• Fix the housing to the flush-moun-
ted junction box by means of the two
screws provided, figure 8, making
sure that it is the right way up.
• Push the thermostat body fully
into the housing and attach the
front panel.
Insert the tab L.
NOTE. The thermostat is supplied
with three adapters to allow for
Fig. 8
