4 TECHNICAL DATA
18
Screw, shift shaft deflector on shift
shaft
M6 18 Nm (13.3 lbf ft)
Loctite
®
243™
Screw, steering damper bracket on
frame
M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, step plate for foot brake
lever
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, voltage regulator M6 6 Nm (4.4 lbf ft)
Nut, exhaust valve throttle cable M6x1 5 Nm (3.7 lbf ft)
Screw, footrest unit adjustment M6x17 10 Nm (7.4 lbf ft)
Loctite
®
243™
Cable disk nut, exhaust valve M8 7 Nm (5.2 lbf ft)
Nut, rear sprocket M8 36 Nm (26.6 lbf ft)
Loctite
®
243™
Nut, shift rod M8 12 Nm (8.9 lbf ft)
Nut, valve M8 6 Nm (4.4 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, axle clamp M8 15 Nm (11.1 lbf ft)
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft)
Screw, foot brake lever M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, front brake disc M8 28 Nm (20.7 lbf ft)
Loctite
®
2701™
Screw, front rider footrest bracket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, ignition lock (tamper-proof
screw)
M8 25 Nm (18.4 lbf ft)
Screw, passenger footrest unit M8x25 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, passenger footrest unit M8x35 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, rear brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, rear brake disc M8 28 Nm (20.7 lbf ft)
Loctite
®
243™
Screw, shift lever on footrest sup-
port
M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, side stand bracket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, side stand spring M8 15 Nm (11.1 lbf ft)
Loctite
®
2701™
Screw, steering damper on holder M8 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, steering damper on triple
clamp
M8 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, steering stem clamp M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
