TECHNICAL DATA 4
19
Screw, subframe M8 35 Nm (25.8 lbf ft)
Loctite
®
243™
Screw, subframe M8 28 Nm (20.7 lbf ft)
Loctite
®
243™
Screw, subframe brace M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, subframe metal flange M8 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 18 Nm (13.3 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, engine bearer M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, front brake caliper M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, side stand M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft)
Banjo bolt, brake line, connecting
piece, rear
M10x1 25 Nm (18.4 lbf ft)
Nut, rear hub shock absorber car-
rier
M10x1.25 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, bottom shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
243™
Screw, brake caliper support M12 28 Nm (20.7 lbf ft)
Screw, side stand bracket M12 80 Nm (59 lbf ft)
Loctite
®
243™
Screw, top shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
243™
Screw, triangular lever on link fork M12 80 Nm (59 lbf ft)
Loctite
®
243™
Lambda sensor M12x1.25 24.5 Nm (18.07 lbf ft)
Screw, eccentric M16 70 Nm (51.6 lbf ft)
Nut, fork pivot M19x1.5 130 Nm (95.9 lbf ft)
Thread greased
Screw, shock absorber support M20x1.5 10 Nm (7.4 lbf ft)
Thread and fitting greased
Screw, steering head, top M20x1.5 12 Nm (8.9 lbf ft)
Nut, seat lock M22x1.5 3 Nm (2.2 lbf ft)
Screw, front wheel spindle M25x1.5 45 Nm (33.2 lbf ft)
Thread greased
Nut, rear axle, shock absorber side M35x1.5 200 Nm (147.5 lbf ft)
Loctite
®
262™/lock the locking wire
with locking varnish
Nut, rear axle M50x1.5 250 Nm (184.4 lbf ft)
Thread greased/lock locking wire
with locking varnish
