NO REQ'D PART NO. DESCRIPTION
1 1 85663 Boom Cylinder Assembly
1 53031 90° Grease Zerk
2 As Req'd 6623 Thrust Washer 1.38" X .031"
As Req'd 64724 Thrust Washer 1.38" X .090"
As Req'd 64725 Thrust Washer 1.38" X .125"
3 1 85672 Dipper Cylinder Assembly
2 6616 Grease Zerk
4 3 1043 .38" UNC X 1.00" Hex Capscrew
5 1 1503 .38" Lock Washer
6 1 81881 Clamp Plate
7 1 81882 Rubber Spacer
8 3 6616 Grease Zerk
9 - 81610 Bushing (Included in Boom) (Install with Locktite Grade 680)
10 1 81678 Pin
11 4 1650 Snap Ring
12 2 6562 Spring Washer
13 1 1959 .88" UNC Jam Lock Nut
14 1 82223 Boom (Includes (4) 81610 Bushings)
15 1 83656 Handle Grip
16 1 83606 Swing Lock Bracket
17 1 86897 .88" UNC Bolt
18 2 1961 .38" UNC X .50" Flange Head Hex Capscrew
19 1 86639 Boom Lock
20 1 86880 Pin 1.38" x 6.66" (Serial #---11168 and UP)
81677 Pin 1.38" x 5.78" (UP to Serial #---11168)
21 2 1837 .38" UNC Lock Nut
22 2 1514 .38" Flat Washer
23 2 82859 Double Hose Clamp
24 1 34128 Rubber Edge - 12"
25 1 1972 Roll Pin
26 1 34125 Hose Sock
27 1 53167 Hose Clamp
BOOM & DIPPER ASSEMBLY
ASSEMBLY #85699
7456
12-14-99-2
SERIAL #8408AX973 AND UP
NOTE:
(1) Pivot Pin #81678 is sold only in Pin Kit #86312. Kit includes one pin
#81678, two thrust washers #6623 and two snap rings #1650.
(2) Pivot Pin #81677 is sold only in Pin Kit #86313. Kit includes one pin
#81677, two thrust washers #6623 and two snap rings #1650.
(3) Pivot Pin #86880 is sold only in Pin Kit #86881. Kit includes one pin
#86880, two thrust washers #6623, two snap rings #1650 and one grease zerk
#6616.
(1)
(3)
(2)
To Next Page
