Bradley S19-921 - Pre-Installation Information; Components

2 9/12/07 Bradley Corporation • 215-1546 Rev. C; ECN 07-525
S19-921, S19-921H, S19-921HR Installation
Pre-Installation Information
Overview
This self-contained gravity-fed eyewash flushes eyes for 15 minutes at a minimum of 0.4 gallons/minute by using
only 7 gallons of water. It can be transported when empty but should be placed in a fixed location when completely
assembled and filled with fluid. The On-Site® complies with ANSI standard Z358.1-2004.
Components
Tank: Tank is made of transparent yellow polycarbonate.
Pedestal: Pedestal is made of opaque yellow polyethylene, with a black polyethylene pull-down arm.
Concentrate: Contents of the 8 oz. bottle of water preservative concentrate is mixed with 7 gallons of potable water
in the eyewash tank.
Wall Bracket: Wall bracket is made of stainless steel and is used for mounting the unit to the wall (optional).
Heater Jacket: Yellow insulated/waterproof heater jacket is made of 200-denier foam-backed nylon with clear vinyl
pocket. 121-watt tank heater and 60-watt tube heater are made of silicone rubber with PSA adhesive backing.
Thermostat is 75°F +/- 5°normal operation in series with 90°F +/- 5° high limit, manually reset thermostat.
WARNING
Read this installation manual completely to ensure proper installation, then keep
it with the emergency fixture. Compliance and conformity to drain requirements
and other local codes and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before
discarding any packaging material. If any parts are missing, do not begin
installation until you obtain the missing parts.
Emergency eye wash unit shall be placed in accessible locations that require no
more than ten seconds to reach and should be within a travel distance no greater
than 30.5 m (100 ft) from the hazard (ANSI Z358.1). It is recommended that a
waste container be placed under the eye wash unit during use/testing to collect
spent water. This will help keep the floor dry and provide easy waste disposal.
When drilling into tile, masonry or other materials which make installing wall
anchors difficult, be sure to wear safety goggles to prevent eye injuries.
Solvent-based cleaners may cause plastic parts to degrade which will affect their
performance. Review the materials listed in the "Components" section of this
installation manual with your cleaner's manufacturer prior to use.
The inspection and testing results of this equipment should be recorded weekly
to verify proper operation. This equipment should be inspected annually to
ensure compliance with ANSI Z358.1. Keep the inspection tag with the eyewash.
Workers who may come in contact with potentially hazardous materials should
be trained regarding the placement and proper operation of emergency
equipment per ANSI Z358.1.
This product meets ANSI Z358.1-2004 as a self-contained “gravity-fed” eye wash.
All ANSI approved eye washes must provide a minimum 15-minute water flush
treatment at a minimum of 0.4 GPM.
For questions regarding the operation or installation of this product, visit
www.bradleycorp.com or call 1-800-BRADLEY. Product warranties may also be
found under ”Product Information” on our web site at www.bradleycorp.com.
Installation
