Braeburn 2220NC Detailed Installer Guide

7
Operating Your Thermostat
Setting the System Control Mode
TheSystemControlhasseveralmodesof
operationthatcanbeselectedbymovingthe
SYSTEMswitchtotheappropriateposition.
COOL Onlyyourcoolingsystemwilloperate
OFF Heatingandcoolingsystemsareoff
HEAT Onlyyourheatingsystemwilloperate
Additional Status Indicators (Model 2220NC Only):
EMER Operatesabackupheatsource(EmergencyHeat)forheatpump
 systemsonly
NOTE: If your model 2220NC was configured
for a conventional system (CONV) then you will
not have the EMER (emergency heat) option
and “NO EMER SET” will flash in the display if
EMER is selected with the system switch.
Setting the Fan Control Mode
TheFanControlhas2modesofoperation–AUTOandON.Themodecan
beselectedbymovingtheFANswitchtotheappropriateposition.
AUTO Thesystemfanwillrunonlywhenyour
  heatingorcoolingsystemisrunning
ON Thesystemfanwillruncontinually
Temperature Adjustment
Temporary Adjustment–Presstheorbuttontoadjustthecurrent
setpointtemperature.
Extended Adjustment–PresstheHOLDbuttonsothatHOLDappearsin
thedisplayscreen.Pressortoadjustthecurrentsettemperature
(See“ExtendedHoldPeriod”,page8).
10
