Page #10 background image
No. Installer Setting Factory Setting Comments
(
Notes follow this table) Default Options (More information follows this table)
25
Heat Set Point Upper Limit
90LIM 90-60 LIM
Select a Heat Set Point Upper Limit of 90°-60° F
(32°-10° C)
26
Cool Set Point Lower Limit
45LIM 45-80 LIM
Select a Cool Set Point Lower Limit of 45°-80° F
[note 7]
(7°-27° C)
*When a Braeburn
®
outdoor sensor is connected, the thermostat automatically recognizes it. Press PROG and HOLD at the
same time to display outdoor temperature.
NOTE: Additional options such as Service Monitors, setting the lock code, etc. are located in the
User Settings – See User manual for information on setting these options.
Installer Manual 10
NOTES - Installer Settings
1 Only available if Residential profile was selected in option 1.
2 Only available if a 2 or 3 stage system type was selected in option 6.
3 Only available if a Conventional system was selected in option 6.
4 Only available if a 2 or 3 stage Heat Pump system was selected in option 6.
5 Only available if a Heat Pump system was selected in option 6.
6 Only available if the 24 Volt AC common wire is connected to the C terminal.
7 Not available if a heat only hydronic system is selected in option 6.
8 Only available if a programmable profile was selected in option 2.
9 Only available if a Braeburn® indoor remote sensor was connected.
10 Only available if auto changeover was enabled in option 5.
11 Only available if a Braeburn outdoor sensor was connected.
Detailed Explanation of Installer Settings (also see NOTES above):
1 Profile – Selects a residential (RES) or commercial (COMM) profile. If residential is selected, 4 programming
events per day are available. If commercial is selected, 2 event, 7 day programming is available.
2 Programming Mode [note 1] – Selects the programming mode, either full 7 day or 5-2 day (weekday/
weekend) programming or non-programmable.
3 Clock Type – Selects either a 12 hour or 24 hour clock.
4 Temperature Scale – Selects a temperature scale of either °F or °C.
5 Auto Changeover – Selects auto changeover on or off. When auto changeover mode is enabled and
selected, the system automatically switches between heating and cooling modes. There is a 5 minute
delay when switching from heating to cooling or cooling to heating in auto changeover mode.
NOTE: Also see “Auto Changeover Dead Band” in option 22.
6 System Type – Selects the system type for your installation. NOTE: Changes made to this option will
reset options 7 through 15 back to their default values dependant on the system type.
7 1st Stage Differential – Selects a 1st stage temperature differential.
