BRASS MONKEY GH1646 - Power Display and Settings; Battery Power Indicator; Cable Length Specifications; Temperature Setting Range

6
Battery electric power display
Temperature setting
Section Display Battery LevelBattery Level
1 9.7V
2 10.4V
3 11.1V
4 11.8V
5 12.5V
6 13.2V
Cable Area 12V Max Cable Length 24V Max Cable Length
mm
2
AWG mm ftft mm ftft
2.5 12 <2.5 <8 <5 <16
4 12 < 4 <13 <8 <26
6 10 < 6 <20 <12 <39
10 8 <10 <33 <20 <66
Buzzing
If you press any button, the refrigerator will have a buzzer alarm sound. When the
battery level reaches 1, a buzzer alarm will sound.
Cable Length Specification
The DC cables must have a suitable cross-section for their length.
The length is from the battery to the refrigerator.
Temperature setting range: -20°C~20°C
The LCD Display range: -20°C~40°C
