Braun A1 series

Page 9
Pump Module Parts List
* Apply red #271 Thread Locker Loctite
®
to the four hex bolts (items 36 and 37) if a blue nylon patch is not present on
the bolts when retrofitting an M268-0113 pump assembly. Loctite
®
is available from The Braun Corporation under part
number 11522.
t Indicates items available for replacement part purposes only. These items are not included with replacement pump
modules.
Item Qty. Description Part No.
1 Pump Module (complete), 12 Volt, Rear 917-A1516RNA
1 1 Pump Assembly (M268-0113) 12V-120G - Dual Relief / ARS (Includes Items 2 & 3) 31038-12V
2 1 Power Cable, Up Solenoid to Motor 29049
3 1 Solenoid, Up - 4-Post - Trombetta 31129
4 1 Diode Assembly, Up Solenoid 73906A
5 4 Nut, #10-32, Serrated Flange 83080
6 2 Fitting, Male 7/16-20 O-Ring to Male 7/16-20 JIC 37° 24504
7 1 Elbow, Female Swivel 7/16-20 JIC 37° to (2) Male 7/16-20 JIC 37° 26579
8 1 Switch, Pressure 31199
9 1 Control, Hand Pendant Assembly - Standard (Includes Items 10-18) 100063-001
10 1 Keypad, Hand Control 30000
11 1 Hand Pendant Case - Front 100027-001
12 1 Seal, Hand Control - Standard 100066-001
13 1 Module, Hand Control 100041-001
14 1 Screw, 10-32 x 1/2”, Phillip, Pan Head 82744
15 1 Hand Pendant Case - Rear 100028-001
16 1 Hanger, Round - Hand Control 73793
17 2 Screw, #4-40 x 1/4”, Phillip, Pan Head 11480
18 1 Cord, Coiled - 6-Conductor 100044-001
19 1 Shield, Electrical 31304
20 1 Control Board Assembly 100080-001
21 1 Plate, Backing / Mounting - Rear 985-0501RN
22 8 Standoff, Snap-In 31011
23 1 Cover, Pump, 2-Piece - Back
(Complete Assembly 915-0513RNA Includes Items 23 - 30) 915-0513RN
24 1 Recepticle, Clip On 28803
25 1 Lens, Threshold Warning - Red 30704
26 1 Decal, Warning / Pressure Relief Valve (Not shown - see Decal Section) 22249
27 1 Spacer, Lens - NHTSA 31386
28 1 Metal Ring Base - Lamp 30971
29 1 Socket, Lamp 30703
30 3 Screw, #8-32 x 1/2” Pan Head Phillips - Thread Cut 30974
31 1 Bulb, Light 19841
32 1 Diode, Green LED, Panel Mount 29545
33 1 Strain Relief - Liquid Tight 30753
34 1 Rivet, Snap, .201” x .217”/.256” 25973
35 2 Washer, 5/16” Flat 10063
36 2 Bolt, 5/16-18 x 3/4”, Nylock, Hex * See note below 29608
37 2 Bolt, 5/16-18 x 1/2”, Nylock, Hex * See note below 10012
38 1 Cable, Ground 26161A
39 1 Washer, 5/16” External Tooth 16368
40 1 Beeper, Continuous 30487
41 1 Switch, Toggle 12185
42 1 Decal, Lift Power - On/Off (Not shown - see Decal Section) 21494
43 1 Stud, Power Feed 26084
44 1 Rubber Boot, Red tSee note below 82046
45 1 Harness, Interlock Interface 31077A
46 1 Pump Handle with Grip 17206A
47 1 Cover, Pump - 2-Piece - Top / Front
(Complete Assembly 915-0519RNA Includes Items 47 - 59) 915-0519RN
48 3 Rivet, Pop, SD43BS - 1/8” - .13”/.19” 12954
49 1 Plug, Window - Clear 30443
50 1 Stud, Wing Head - 1/4 Turn 28804
51 1 Retainer, Push On 28805
52 1 Washer, Nylon, 1/4” I.D. x 11/16” O.D. x .030” 12690
53 1 Clip, Pump Handle - Top 915-5517
54 1 Clip, Pump Handle - Bottom 915-5518
55 1 Decal, Manual Instructions - Public (Not shown - see Decal Section) 31412
56 1 Decal, Removal / Installaton - Pump Cover (Not shown - see Decal Section) 29051
57 1 Decal, Warning - Control Board Damage - ESD (Not shown - see Decal Section) 30787
58 1 Decal, Removal / Installation Pump Handle (Not shown - see Decal Section) 29052
59 1 Decal, Installation & Warning - Hydraulic Pressure Switch (Not shown - see Decal Section) 27154
60 1 Clamp, Hose - Solenoid Mounting 29663
61 1 Ground Wire, Motor 31263A
62 1 Solenoid, 4-Post 28308MOD
