Page 10
Pump Module Diagram
Pump Mounting Bolts
Apply red #271 Thread Locker Locktite
®
to the three pump mounting bolts (items
37 and 38) if a blue nylon patch is not
present on the bolts when retrofitting an
M268 pump assembly. Loctite
®
is
available from The Braun Corporation
under part number 11522-1.
