Braun A1 series User Manual

Page 6
Hydraulic Schematic
Roll Stop
Cylinder
Orifice
Pump Side
Cylinder
BACKUP
PUMP
2100
PSI
Secondary
Valve
Folding
Relief Valve
Lifting
Relief Valve
Down
Valve
1900
PSI
PUMP
Opposite
Pump
Cylinder
M
Orifice
Bridging
Valve
800
PSI
.50 GPM
Roll Stop Fold
Pressure Switch
Fixed Displacement
Pump
Vented Reservoir
Orifice
Backup Pump
Single Acting Cylinder
Check Valve
Manual
Shutoff Valve
Pressure Switch
2 Way 2 Position
Solenoid Valve
Pressure Compensated
Flow Control
Relief Valve
Description Symbol Description Symbol
Filter Screen
Unfold Orifice
M
Pump Motor
Hydraulic Port
