Page 8
Lift Installation Instructions
Installation Parts
Please check the Installation Parts List and Tools List to see that you have everything needed to begin.
Report any missing items.
Tools Required
• Pencil • Wire stripper/Utility knife • 1-1/8" Diameter hole saw
• Tape measure • 3/8" Capacity drill • 1/4" Hex nut driver bit or
• Framing square • 1/8" Diameter drill bit • 1/4" socket/wrench
• Hammer • 3/8" Diameter drill bit • Ratchet-style wrench
• Center punch • 9/16" Wrenches and/or socket
Part Number
Item Qty. Description 12 Volt 24 Volt
1 Installation Parts Package (complete) Includes all following items 25853A-A4 26155A-A4
1 2 Bracket, Underfloor, Reinforcement 25915 25915
1 Small Parts Package (Bag) only (includes items 2-17 only) 25926A 25926A
2 2 Bolt, 3/8"-16 x 8" Hex Tap (Full Thread) 10778 10778
3 8 Bolt, 3/8"-16 x 4" Carriage 23977 23977
4 1 Bolt, 3/8"-16 x 1" Hex 10025 10025
5 8 Washer, 2.469" O.D. x .5" I.D., Flat 13342 13342
6 14 Washer, 3/8" Flat 10064 10064
7 4 Washer, 3/8" Lock 10069 10069
8 8 Washer, 3/8" External Tooth Star 25844 25844
9 10 Nut, 3/8"-16 Hex 10059 10059
10 18 Screw, #8-18 x 1/2" Hex, Self-Tap 10383 10383
11 6 Screw, #8-18 x 1" Hex, Self-Tap 10084 10084
12 10 Clip, Cable, 7/16" Diameter Plastic 15777 15777
13 5 Cable Tie, 11" Solid 10091 10091
14 1 Grommet, Plastic 205-2001 205-2001
15 1 Terminal, Battery Cable, 1/4" eye 13865 13865
16 1 Boot, Rubber, Battery Cable 82046 82046
17 1 Spacer, 13/32" I.D. x 1/2"
See Circuit Sentry Installation
13050 13050
18 1 Circuit Sentry Assembly
See Circuit Sentry Installation
18189A 18190A
19 1 Plastic, Flat 1/8" x 4" x 4"
See Circuit Sentry Installation
12764 12764
20 1 Lead Wire - 30" 13362A 13362A
21 1 Control Box Holder Assembly Includes: 17019A 17019A
22 1 Plate, Back 16988 16988
23 1 Bracket, Switchbox Clip 16954 16954
24 2 Decal, Courtesy Requested 12375 12375
25 1 Decal, Warnings/Operating Instructions 25859 25859
26 1 Decal, Instructions, ADA (Standee/Interlock) 19342 19342
27 1 Video, Commercial Lift Operation 23554 23554
28 1 Manual, Installation/Service 25522-05 25522-05
29 2 Grip, Handrail, Yellow 19074 19074
Power Cable and Base Plate Wedges: These items fastened to the lift platform during shipment.
