70
Multiple lines connected to one Connecting multiple infusion lines with
patient port different flow rates may affect the rate
for all infusions past the point of
connection.
Selectable delivery rates Continuous infusion rate range / bolus
rates in dependence on syringe sizes:
Rate increments 0.01 - 99.99 ml/h in increments of
0.01 ml/h
100.0 - 999.9 ml/h in increments of
0.1 ml/h
Accuracy of bolus infusion typ. ± 2 %
Max. bolus after bolus reduction £ 0.2 ml
KVO-rate Delivery rate > 10 ml/h: KVO-rate 3 ml/h
Delivery rate < 10 ml/h: KVO-rate 1 ml/h
Delivery rate < 1 ml/h: KVO-rate =
set rate (default setting 0.1 ml/h)
Computer connection USB connection in combination with
B. Braun interface lead CAN SP
(8713230) including electrical
insulation. Please pay attention to
safety notices.
History protocol < 3000 last history entries.
100 events for system diagnose.
Refer to separate documents of the
History Viewer for closer information.
Alarm volume 9 levels from 1 (59dBA) to 9 (74dBA)
• Use only pressure proof and compatible disposable items (min. 2 bar/1500 mm Hg)
to avoid influencing performance data - which would result in impairing patient
safety.
Chapter 10
TECHNICAL DATA
Syringe sizes Cont. rates* Bolus rates
[ml] [ml/h] [ml/h]
50/60 0.01 - 200 1 - 1800
optional
0.01 - 999.9
30/35 0.01 -100 1 - 1200
20 0.01 -100 1 - 800
10/12 0.01 -50 1- 500
5/6 0.01 -50 1 - 300
2/3 0.01 -25 1 - 150
