Braun UVL Series User Manual

Page 39
Manual Operating Instructions
DOWN (To Unfold Outer Barrier):
1. Remove hairpin cotter from
detent pin (see Figure D).
2. Remove detent pin.
3. Unfold (rotate) barrier down.
OUT (To Extend Platform):
1. Pull T-Handle (see Figure A).
2. Turn T-Handle to lock platform
in released position.
3. Pull platform out.
4. Turn T-Handle.
5. Push T-Handle in.
6. Grasp outer barrier and
attempt to move platform in
and out until the platform locks
(feel release mechanism
engage).
DOWN (To Lower Platform):
Using hand pump handle, open
hand pump valve (turn counter-
clockwise). See Figure B. Open
1/2 turn only.
UP (To Fold Outer Barrier):
1. Fold (rotate) barrier up.
2. Insert detent pin (see Figure D).
3. Insert hairpin cotter in detent
pin.
UP (To Raise Platform):
Using hand pump handle:
1. Close hand pump valve (turn
clockwise). See Figure B.
2. Insert handle in pump and
stroke. See Figure C.
IN (To Stow Platform):
1. Raise or lower platform to
stow level (follow UP or
DOWN procedures).
2. Pull T-Handle. See Figure A.
3. Turn T-Handle to lock platform
in released position.
4. Push platform in.
5. Turn T-Handle.
6. Push T-Handle in.
7. Grasp outer barrier and
attempt to move platform in
and out until the platform locks
(feel release mechanism
engage).
Note: Close hand pump valve
before operating electric pump.
