Page 49
Maintenance and Lubrication Schedule
Perform all procedures listed in previous section also
1500
Cycles
Apply Light Oil - See Lubrication Diagram
Apply Light Oil - See Lubrication Diagram
Apply Door Ease - See Lubrication Diagram. Apply
to the surface area around both slots and wipe off
excess
Apply Light Oil - See Lubrication Diagram
Apply Light Oil - See Lubrication Diagram
Apply Synthetic Grease - See Lubrication Diagram
Use compressor and nozzle to remove all debris
from housing. Clean outboard lower pan slot and
apply Antiseize to slot before reinstalling pan.
Use clean cloth and solvent to clean tracks. Clean
outboard lower pan slot and apply Antiseize to slot
before reinstalling pan.
Correct or replace damaged parts and/or relubricate.
See Drive Chain Adjustment in Service Manual.
Carriage rollers (bearings)
Eccentric shaft rollers (bearings)
Lifting arm slots in rolling horizontal carriage arm
tubes
Hydraulic cylinder pivot points (4 per cylinder)
Drive chain and chain rollers
Drive chain release latch mechanism
Deploy lift, remove inboard and outboard lower
pans and blow out housing. Blow off platform
also.
Deploy lift, remove inboard and outboard lower
pans and clean housing tracks
Check drive chain tensioner, jam nuts and con-
necting link for securement and/or misalignment.
