BraunAbility Century 2 - Pump Module Parts List

Page 20
NDCC954A34x54R NDCC954A34x54L
Item Qty. Description NDCC954A34x54RHB NDCC954A34x54LHB
1 Pump Module (complete), 12 Volt, Rear 954-5516FNA 954-5516RNA
1 1 Pump Assembly (M268-0114) 12V-120G - Dual Relief (Includes Items 1, 2 & 20) 32858-12V 32858-12V
2 1 Solenoid, Up - 4-Post Trombetta - Angle 35310 35310
3 1 Housing, Pump
(Complete Assembly 947-2513RNA (Rear) or 947-2513FNA (Front) Incl. Items 3 - 21) 947-2513FNBM 947-2513RNBM
4 1 Beeper, Constant - High Output 33251 33251
5 1 Switch, Toggle w/ Gold Contacts 31787 31787
6 1 Stud, Power Feed 26084 26084
7 1 Lens, Threshold Warning - Red 30704 30704
8 1 Spacer, Lens - NHTSA 31386 31386
9 1 Metal Ring Base - Lamp 30971 30971
10 1 Socket, Lamp 30703 30703
11 3 Screw, #8-32 x 1/2" Pan Head Phillips - Thread Cut 30974 30974
12 1 Bulb, Light 19841 19841
13 2 Clamp, Spring - Pump Handle
✓See note below 12350 12350
14 4 Rivet, Pop, SD43BS - 1/8" - .13"/.19" 12954 12954
15 2 Rivet, Pop, SD62BS - 3/16" - .06"/.13"
✓See note below 11512 11512
16 3 Rivet, Lock, Black, 0.22" x .11"/.15" 38456 38456
17 1 Screw, T-Head, 10-32 x 3/8", Thumb
✓See note below 33435 33435
18 1 Diode, Green LED - Panel Mount 29545 29545
19 1 Circuit Breaker, Manual Reset - 15 Amps 35143 35143
20 1 Clamp, Hose - Solenoid Mounting 29663 29663
21 1 Harness, Lift Power
✓See note below 33688A 33688A
22 1 Elbow, Female Swivel 7/16-20 JIC 37° to (2) Male 7/16-20 JIC 37° 26579 26579
23 4 Rivet, Snap, .122" Dia. - .158 -.197" Thick 25759 25759
24 4 Washer, 5/16" External Tooth 16368 16368
25 2 Bolt, 5/16-18 x 3/4", Nylock, Hex * See note below 29608 29608
26 2 Bolt, 5/16-18 x 1/2", Nylock, Hex * See note below 10012 10012
27 1 Cover, Pump Module
✓See note below 947-2519FNBM 947-2519RNBM
28 1 Pump Handle with Grip
✓See note below 17206A 17206A
29 1 Cycle Counter, LCD w/o Reset 30547 30547
30 1 Flasher, 12V 32461 32461
31 2 Relay, 30/40A SPDT 12V with Internal Diode 35249 35249
32 1 Diode Assembly, Up Solenoid 73906A 73906A
33 1 Cable, Pump Module Power 26082A-4 26082A-4
34 1 Harness, Main 945-2500NA 945-2500NA
35 1 Fitting, Male 7/16-20 O-Ring to Male 7/16-20 JIC 37° 24504 24504
36 1 Cable, Lift / Chassis Ground 22166A 22166A
37 1 Wire Assembly, Lift Interlock Connection 31797A 31797A
38 1 Wire Assembly, Lift Stowed Connection
✓See note below 31798A 31798A
39 1 Rubber Boot, Red
✓See note below 82046 82046
40 1
Control, Hand Pendant Assembly - Non Electronic / Non Shielded - Coiled ✓See note below 33659A 33659A
41 1 Harness, Tower / Opposite Platform
✓ (Not shown - see Wiring Diagram) 37009A 37009A
42 1 Harness, Bridge Inputs - Platform
✓ (Not shown - see Wiring Diagram) 33373FA-954 33373RA-954
43 1 Harness, Stow - Platform
✓ (Not shown - see Wiring Diagram) 33377FA-954 33377RA-954
44 1 Harness, Tower / Pump - Platform
✓ (Not shown - see Wiring Diagram) 37014A 37014A
45 1 Harness, Extension Lighting - 61.5"
✓ (Not shown - see Wiring Diagram) 31033A61.5 31033A61.5
46 1 Harness, Extension Lighting - 103.5"
✓ (Not shown - see Wiring Diagram) 31033A103.5 31033A103.5
47 1 Hose Assembly, 90" - 1/8" Dia.-Swivel Ends
✓ (Not shown - see Hydraulic Diagram) 16004A-090 16004A-090
48 1 Hose Assembly, 51" - 1/8" Dia.-Swivel Ends
✓ (Not shown - see Hydraulic Diagram) 16004A-051 16004A-051
49 1 Hose, 1/8" Thermal Plastic
✓ (Not shown - see Hydraulic Diagram) 23742R 23742R
50 1 Kit, Hydraulic Port Service Cap
✓ (Not shown - see Hydraulic Diagram) 27049K 27049K
51 1 Decal, Warning / Pressure Relief Valve (Not shown)
✓See note below 22249 22249
52 1 Decal, Lift Power - On/Off (Not shown) 21494 21494
53 1 Decal, Dual Relief Valve Adjustment (Not shown)
✓See note below 32201 32201
54 1 Decal, Manual Instructions - Public (Not shown)
✓See note below 32940 32940
55 1 Connector, Plastic "Y", 1/8" O.D. (Not Shown) 18877 18877
Pump Module Parts List
* Apply Loctite
®
Threadlocker Red 271™or equivalent to the three pump mounting bolts (items 25 and 26) if a blue
nylonpatchisnotpresentontheboltswhenretrottinganM268-0114pumpassembly.
✓ Indicates items available for replacement part purposes only. These items are not included with replacement pump
modules.
