Page 22
Rear Pump Module Parts List
Item Qty. Description NL917IB3751-2
1 Pump Module (complete), 12 Volt, Rear 947-5516RNA
1 1 Pump Assembly (M268-0144) 12V-120G - Mahle Motor (Includes Items 1, 2 & 20) 404114
2 1 Solenoid, Up - 4-Post Trombetta - Angle 35310
3 1 Housing, Pump
(Complete Assembly 947-2513RNA or 947-2513FNA Includes Items 3 - 17)
947-2513RNBM
4 1 Beeper, Constant - High Output 33251
5 1 Switch, Toggle w/ Gold Contacts 31787
6 1 Stud, Power Feed 26084
7 1 Lens, Threshold Warning - Red 30704
8 1 Diode, Green LED 29545
9 1 Metal Ring Base - Lamp 30971
10 1 Socket, Lamp 30703
11 3 Screw, #8-32 x 1/2" Pan Head Phillips - Thread Cut 30974
12 1 Bulb, Light 19841
13 2 Clamp, Spring - Pump Handle 12350
14 4 Rivet, Pop, SD43BS - 1/8" - .13"/.19" 12954
15 2 Rivet, Pop, SD62BS - 3/16" - .13"/.25" 11512
16 1 Screw, #10-32 x 3/8", T-Head, Thumb 33435
17 1 Circuit Breaker, Manual Reset - 15 Amp 35143
18 4 Rivet, Lock-Black 38456
19 1 Harness, Lift Power tSee note below 33688A
20 1 Clamp, Hose - Solenoid Mounting 29663
21 2 Fitting, Male 7/16-20 O-Ring to Male 7/16-20 JIC 37° 24504
22 1 Elbow, Female Swivel 7/16-20 JIC 37° to (2) Male 7/16-20 JIC 37° 26579
23 4 Rivet, Snap, .122" Dia. - .158" -.197" Thick 25759
24 4 Washer, 5/16" External Tooth 16368
25 2 Bolt, 5/16-18 x 3/4", Nylock, Hex * See note below 29608
26 2 Bolt, 5/16-18 x 1/2", Nylock, Hex * See note below 10012
27 1 Cover, Pump Module 947-2519RNBM
28 1 Pump Handle with Grip 403728
29 1 Cycle Counter, LCD w/o Reset 30547
30 1 Flasher, 12V 32461
31 2 Relay, 30/40A SPDT 12V with Internal Diode 35249
32 1 Harness, Main 947-2500NA
33 1 Cable, Pump Module Power 26082A-4
34 1 Cable, Lift / Chassis Ground 22166A
35 1 Wire Assembly, Lift Interlock Connection 31797A
36 1 Wire Assembly, Lift Stowed Connection tSee note below 31798A
37 1 Rubber Boot, Red tSee note below 82046
38 1 Control, Hand Pendant Assembly - Non Electronic / Non Shielded - Coiled tSee note below 33659A
39 1 Diode Assembly, Up Solenoid 73906A
40 1 Harness, Tower / Opposite Pump (Not shown - see Wiring Diagram) 37009A
41 1 Harness, Bridge Inputs (Not shown - see Wiring Diagram) 33249RA
42 1 Harness, IB Occupied / Stow (Not shown - see Wiring Diagram) 33257A
43 1 Harness, Tower / Pump Side (Not shown - see Wiring Diagram) 37014A
44 1 Harness, Extension Lighting - 54" (Not shown - see Wiring Diagram) 31033A54
45 1 Harness, Extension Lighting - 103.5" (Not shown - see Wiring Diagram) 31033A103.5
46 1 Hose Assembly, 90" - 1/8" Dia. - Swivel Ends (Not shown - see Hydraulic Diagram) 16004A-090
47 1 Hose Assembly, 46" - 1/8" Dia. - Swivel Ends (Not shown - see Hydraulic Diagram) 16004A-046
48 1 Hose Assembly, 3/16" Dia. w/Two Guards (Not shown - see Hydraulic Diagram) 915-2601-139
49 1 Hose, 1/8" Thermal Plastic (Not shown - see Hydraulic Diagram) 23742R
50 1 Decal, Warning / Pressure Relief Valve (Not shown) tSee note below 22249
51 1 Decal, Lift Power - On/Off (Not shown) tSee note below 21494
52 1 Decal, Fold & Barrier Relief Valve Adjustment (Not shown) tSee note below 33223
53 1 Decal, Manual Instructions - Public (Not shown) tSee note below 32940
54 1 Connector-Plastic Y - 1/8" OD (Not shown) 18877
55 1 Kit, Hydraulic Port Service (Not shown) 27049K
56 1 Harness, Dual Pump Side Retro - Series EA / Serial # / Rev A Only (Not shown) 400209A
* Apply Locktite
®
Threadlocker Red 271™ or equivalent to the three pump mounting bolts (items 25 and 26) if a blue
nylonpatchisnotpresentontheboltswhenretrottinganM268-0117pumpassembly.
t Indicates items available for replacement part purposes only. These items are not included with replacement pump
modules.
Applicable for NL917IB3751-2
