BraunAbility Millennium 2 NL - Bottom Parallel Arm Assembly

Page 36
Exploded Views and Parts Lists
Bottom Parallel Arm Assembly - Pump Side
Bottom Parallel Arm Assembly - Opposite Pump Side
1
2
ARM-PARALLEL/BOTTOM (Incl. Items 1&2)1
DESCRIPTIONQTY.ITEM PART NO.
945-4412NAKS1
2 BEARING-FLANGE-3/4" X 3/8"-12FDU064 24011
1
2
ARM-PARALLEL/BOTTOM-SWITCH (Incl. Items 1-4)
BEARING-FLANGE-3/4" X 3/8"-12FDU06
ASSY-IB OCCUPIED3
2
1
32514NAKS1
945-4458NAKS
240114
1
ITEM
PART NO.
QTY. DESCRIPTION
NUT-#10-32 W/LOCKWASHER/AUTO-BK4 183492
4
3
1
2
ARM-PARALLEL/BOTTOM (Incl. Items 1&2)1
DESCRIPTIONQTY.ITEM PART NO.
945-4412NAKS1
2 BEARING-FLANGE-3/4" X 3/8"-12FDU064 24011
1
2
ARM-PARALLEL/BOTTOM-SWITCH (Incl. Items 1-4)
BEARING-FLANGE-3/4" X 3/8"-12FDU06
ASSY-IB OCCUPIED3
2
1
32514NAKS
1
945-4458NAKS
240114
1
ITEM
PART NO.
QTY. DESCRIPTION
NUT-#10-32 W/LOCKWASHER/AUTO-BK4 183492
4
3
NL917IB-2
NL917FIB-2
NL917IB3454-2
NL917FIB3454-2
NL917FIB3551-2
NL919IB-2
NL919FIB-2
NL917IB-2
NL917FIB-2
NL917IB3454-2
NL917FIB3454-2
NL917FIB3551-2
NL919IB-2
NL919FIB-2
Applicable Lifts:
Applicable Lifts:
