Page 2
UP
DOWN
32819
FOLD
UNFOLD
32820
Pump Module (Front)
Hand-Held Pendant Control
Base Plate
Top Parallel Arms (2)
Adjustable Quiet-Ride Stow Blocks (2)
Main Cylinders (2)
Vertical Arm Covers (4)
Pump Side Vertical Arm
Handrails (2)
Outer Barrier Cylinder
(not visible - underside of platform)
Outer Barrier
(Automatic Outboard Roll Stop)
Saddle (2)
Outer Fold Arm (2)
Opposite Pump Side
Vertical Arm
Bottom Parallel
Arms (2)
Platform Lights (2)
Rear
Front
Outboard
(passenger's side)
Inboard
(driver's side)
“Arrows/30°-30°”6-13-90
(of vehicle)
(of vehicle)
Outboard
Right (Front)
Lift-Tite
™
Latches (2)
Unfold Assist Compression Springs (2)
Outer Barrier Latch
Platform Side Plates (2)
Platform
Left (Rear)
Inboard
Towers (2)
Threshold
Warning
Plate
Audible Threshold Warning
(not visible)
Visual Threshold Warning
Inner Roll Stop
Lift Terminology
Inner Fold Arm (2)
To Next Page
