BraunAbility Vista 2 - Secure Lift

Page 19Page 18
UP
DOWN
32819
FOLD
UNFOLD
32820
®
Lift Installation
Turnbuckle Installation and Adjustment
D
Left
Turnbuckle
Right
Turnbuckle
Stop
Block
Vertical
Arm
Stop block must solidly
contact vertical arm.
Platform
Bracket
Turnbuckle
Hex Nut and
Lock Washer
Right
Platform Slot
Left
Platform Tab
Platform
Inboard Ends
Platform
Heel
A
B
C
D
Figure 2
Lift Installation
Platform Half Stabilizer Roller Installation and Adjustment
36514
1. Unfold and lower platform to oor level.
2. Mount UHMW bumpers (Item 2) to mounting
brackets (Item 1) as indicated using 5/16-18
X 2-1/4" carriage bolt (Item 9), roller axle
(Item 8), lock washer (Item 3) and 5/16" hex
nut (Item 4). Tighten securely.
3. Position and mount bracket and bumper
assemblies to lift towers as shown. Secure
to lift using 5/16-18 X 3/4" carriage bolt
(Item 5), 1/4" at washer (Item 6), 5/16" lock
washer (Item 7), and 5/16" acorn nut (Item
10). Snug tighten.
4. Stow lift fully. Push bumpers tightly
against platform halves (oval slots provide
adjustment). Tighten securely. Test for
rattle and adjust as needed.
1
3
4
5
6
7
8
9
2
10
Perform turnbuckle assembly/
adjustment procedures, detailed in
service bulletin 34391, included with lift,
before beginning anti-rattle installation.
Figure A
