BraunAbility Vista 2 - Lift Components and Configuration; Lift Terminology

Page 9Page 8
Lift Terminology
BraunAbility wheelchair lifts provide a method
of boarding and exiting applicable motor
vehicles. BraunAbility wheelchair lifts accom-
modate wheelchair passengers, standees,
and other mobility aid users.
The lift must be installed, operated,
and maintained as detailed in this
manual. Any use of equipment
other than instructed in this manual
is prohibited.
Center of Gravity
Center of Gravity is the intersection of X, Y, and Z.
Lift Model X (cm) Y (cm) Z (cm)
VL998IB3448RP-2
VL998IB3452RP-2
VL998IB3463RP-2
VL996IB3042-2
63.15
63.15
63.15
54.34
57.83
59.32
70.75
44.70
22.07
22.07
22.07
15.12
Notice: X must be measured from opposite pump side as shown.
X
Y
Rear
Front
Outboard
(passenger's side)
Inboard
(driver's side)
“Arrows/30°-30°”6-13-90
(of vehicle)
(of vehicle)
Outboard
Right
Left
Inboard
UP
DOWN
3281
9
FOLD
UNFOLD
32820
®
Pump
Module
Hand-Held
Pendant
Control
Base Plate
Top Parallel Arm (2)
Adjustable Quiet-Ride
Stow Block (2)
Main Cylinder (2)
Vertical Arm Cover (4)
Opposite Pump Side
Vertical Arm
Handrail (2)
Roll Stop
Pump Side Vertical Arm
Bottom Parallel
Arm (2)
Platform Light (2)
Lift-Tite
™
Latch (2)
Roll Stop Foot (2)
Platform Side Plate (2)
Tower (2)
Plaform Half
Anti-Rattle (2)
Saddle (2)
Lower Fold Arm (2)
E-Stop
Bridge Plate
Base
Plate
Cover
Z
