BRAX NOX4 DSP User Manual

TECHNICAL DATA
29
Output power per channel at 4 Ohms......................................................................................................4 x 100 Watts RMS
Output power per channel at 2 Ohms ..................................................................................................... 4 x 170 Watts RMS
Output power bridged at 4 Ohms ...........................................................................................................2 x 340 Watts RMS
Frequency response ....................................................................................................................................... 20 Hz - 20 kHz
Total harmonic distortion..........................................................................................................................................< 0,009%
TIM ..........................................................................................................................................................................< 0,009%
Signal-to-noise ratio................................................................................................................................................... > 95 dB
Damping factor ..............................................................................................................................................................> 600
Input impedance .................................................................................................................................................... 10 kOhms
Input sensitivity ...............................................................................................................................................500 mV - 8,0 V
DSP type ........................................................................................................................................... Audio signal processor
DSP resolution .............................................................................................................................................................. 56-Bit
DSP processing power ............................................................................................................................................ 172 MHz
Signal converter A/D ........................................................................................................................................... Asahi Kasei
Signal converter D/A .................................................................................................................. BurrBrown (3 x 2-channels)
Output voltage RCA outputs ....................................................................................................................................... 6 Volts
Internal fuse .................................................................................................................................................................. 100 A
Operating voltage ...............................................................................................9,2 - 18 Volts (max. 5 sec. down to 6 Volts)
Dimension (H x W x D) ............................................................................................................................ 320 x 320 x 56 mm
.........................................................................................................................12,6 x 12,6 x 2,2 inch
Weight net .................................................................................................................................................................. 7,5 kgs
DSP Features ......%DQG(4ZLWKÄ¿QHDGMXVWPHQW³LQRFWVWHSVDQDGMXVWDEOHTXDOLW\IDFWRUEHWZHHQDQG
............................................................... +LJKDQG/RZSDVV¿OWHULQRFWVWHSV)XOOUDQJHRU+]VWHSV6XEZRRIHU
....................................................................Slope from 0 to 42 dB/Oct. and time alignment in 7 mm / 0,27“ / 0,02 ms steps
......................................................................................... Phase 0/180° (Fullrange) or 0 - 360° in 22,5° steps (Subwoofer)
.......................................DOOHVWDEOLVKHG¿OWHUFKDUDFWHULVWLFV%HVVHO/LQNZLW]%XWWHUZRUWK7VFKHE\VFKHIIDQG6HOI'H¿QH
.............................. Sum signal formation from up to 4 input channels and a free channel routing between in- and outputs
Attention: All channels are set up in fullrange-mode in delivery status

BRAX NOX4 DSP Specifications

General

Brand	BRAX
Model	NOX4 DSP
Category	Car Amplifier
Language	English
