List of Circuit Control Cards (CCC)
8
CCC 2 B 50 highpass 18 dB/Oct. lowpass 18 dB/Oct.
full range
CCC 3 B 70 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 4 B 80 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 5 B 90 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 6 B 100 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 7 B 120 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 8 B 150 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 9 B 180 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 10 B 200 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 11 B 400 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 12 B 600 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 13 B 800 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 14 B 1000 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 15 B 1200 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 16 B 2400 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
CCC 17 B 4200 highpass 18 dB/Oct. lowpass 18 dB/Oct. full range
Card No. Type Frequency CCC Position No.
in Hz 1 2 3 4
CCC 1 A 45 subsonic 18 dB/Oct. full range
CCC 18 C 50 highpass 18 dB/Oct.
lowpass 18 dB/Oct. incl. subsonicfilter
full range
26 Hz; 30 dB/Oct.
CCC 19 C 70 highpass 18 dB/Oct.
lowpass 18 dB/Oct. incl. subsonicfilter
full range
26 Hz; 30 dB/Oct.
CCC 20 C 80 highpass 18 dB/Oct.
lowpass 18 dB/Oct. incl. subsonicfilter
full range
26 Hz; 30 dB/Oct.
CCC 21 C 90 highpass 18 dB/Oct.
lowpass 18 dB/Oct. incl. subsonicfilter
full range
26 Hz; 30 dB/Oct.
CCC 22 C 100 highpass 18 dB/Oct.
lowpass 18 dB/Oct. incl. subsonicfilter
full range
26 Hz; 30 dB/Oct.
CCC 23 C 120 highpass 18 dB/Oct.
lowpass 18 dB/Oct. incl. subsonicfilter
full range
26 Hz; 30 dB/Oct.
Circuit Control Card
Type A
Circuit Control Card
Type B
Circuit Control Card
Type C
On request all triple C’s are available in 6 dB and 12 dB octave.
