7 of 52© 2021 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM EN_TSM-2004-6A Advanced_Set-Up_20211012
SERIES 6A
ADVANCED SETUP GUIDE
5.2.2 Split range


① Positioner 1
② Positioner 2
③ Signal source 0/4 ... 20 mA, terminals 6 and 8
④ Power source 18 ... 30 V, terminals 2 and 8
Figure 9 Series connection of 2 positioners, e.g. split range
Connection
5.2 Electrical wiring
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 10/2020, A5E00074631-AF 81
