BRC Sequent 24 - Annex D: Injectors Cut Diagram

14
✂
✂
✂
✂
Violet
Orange
Violet
Orange
Violet
Orange
Violet
Orange
Violet Violet Violet Violet
Ex
Ex
Ex
Ex
ITALY
M.T.M.
ET 98
White/Brown
Gas 1st
Injector
Gas 2nd
Injector
Gas 4th
Injector
Gas 3rd
Injector
A6
B5 B4 B3 B2
PETROL ECU
A5
White/Green
A4A3A2
White/Green White/Green White/Green
LPG
Solenoid Valve
SEQUENT 24
ECU
External Relé on the
wiring Sequent 24
Positive Petrol
Injector
C1
A7
White/Green
Grenn/Black
Ground
+12V After Contact
Europa
Multivalve
1st Petrol
Inject.
2nd Petrol
Inject.
3rd Petrol
Inject.
4th Petrol
Inject.
ANNEXES D
Injectors cut diagram
