BREN-TRONICS, INC.
10 Brayton Court
Commack, NY 11725
P: 631-499-5155 | F: 631-499-5504
www.bren-tronics.com
Page 22 of 25
ALT 170C
(BTC-70844-2)
PR4G WORKSHOP CHARGER
OPERATION MANUAL
850084 REV D
Data presented in this document is subject to change without notice
3-4 BASIC FUNCTIONAL TEST
1. Turn off all power switches, and remove all adapters.
2. Connect the ALT 170C to AC power.
3. Turn On the AC power switch.
4. The front panel LED’s should light in sequence. Amber, then Green, then Red.
Insure all LED’s light.
5. Insure the POWER-ON LED is lit and that all other indicators are off.
6. Place an Adapter into each of the four ports.
7. Verify that the CHARGE LED blinks for several seconds at each position, then
moves to the next Port.
8. Press each of the Recondition Buttons several times. Verify the Recondition
LED alternates on then off with each press.
9. Place a battery in Port 1 Channel A. Insure that the CHARGE LED blinks
rapidly or turns on solid.
10. Repeat above step for all other ports and channels.
11. Turn off the AC power switch and disconnect AC Power.
12. Connect the ALT 170C to DC Power.
13. Turn On the DC power switch.
14. The front panel LED’s should light in sequence. Amber, then Green, then Red.
Insure all LED’s light.
15. End of Test.
