Disassembling your Breville Juice Fountain
13
Step 1
Turn Juice Fountain ‘Off’ at the power outlet and
unplug.
Step 2
Remove the pulp container by holding the handle
and pivoting the bottom of the pulp container
away from the juicer.
Step 3
Place both hands on either side of the locking
arm and pull back and lift over the grooves on
either side of the juicer cover.
Step 4
Move the locking arm down.
Step 5
Lift the juicer cover off the Juicer.
Operating your Breville Juice Fountain
continued
Step 4
With the motor running, place food into the feed
chute. Using the food pusher, gently guide food down
the feed chute. To extract the maximum amount of
juice, always push the food pusher down slowly.
Step 5
Juice will flow into the juice jug and the separated
pulp will accumulate in the pulp container.
The pulp container can be emptied during juicing
by turning the Juice Fountain ’Off‘ and then
carefully removing the pulp container. (Replace
empty pulp container before continuing to juice).
Do not allow the pulp container to overfill as this
may prevent correct operation or damage the unit.
Note
To minimize washing up place a plastic freezer
bag into the pulp container to collect the pulp.
Note
12
NEVER USE FINGERS TO PUSH FOOD DOWN THE FEED CHUTE OR TO CLEAR THE FEED
CHUTE. ALWAYS USE THE FOOD PUSHER PROVIDED.
4
2
3
4
5
