4. Run water line to brewer location.
A. Run water line behind cabinets through the wall to brewer area.
B. Run water line direct from source to counter top (for example along the side of the refrigerator).
5. Waterline connection to brewer
A. Cut waterline near nal location of brewer.
B. Attached water line to quick connector (supplied).
• place compression nut onto water line
• slide water line onto barbed feature
• tighten compression nut (with wrench)
• note - quick connector has built in valve, water can now be turned on
C. Turn on water supply and check for leaks.
D. Snap quick connector into mating connector on rear of brewer.
• to release connection, press gray tab on connector on brewer.
6. Connect Power
Plug the power cord into an outlet.
Excess cord can be stored in the recess on the back of the Brew Express.
recess tab
water line
compression nut
quick connector
water filter recomended
(not included)
!
!
SET UP
6
