Document #100578 RevJ 16 Printed in USA © 2017
SERVICE
Fuse Replacement (Model 5001 Only)
1. Unplug table from wall receptacle.
2. Push bottom rear drawer to the left to access fuse assembly (Figure 17).
3. Push the fuse holder cap in with a at screwdriver (Figure 18).
4. Rotate 1/4 turn counterclockwise to remove cap and fuse (Figure 19).
5. Replace fuse with Brewer 102007, 3A 250V fuse.
6. Push fuse into cap.
7. Push cap with fuse into fuse holder and rotate 1/4 turn clockwise to install.
8. Plug table into wall receptacle.
9. Check drawer warmer and outlet for proper function.
Figure 18. Fuse Holder CapFigure 17. Bottom Drawer Moved to
Show Fuse Location
Fuse
CLEANING
WARNING
Shock Hazard
Disconnect power by removing plug from
wall receptacle before servicing table.
WARRANTY
For Brewer Warranty Information:
Visit www.brewercompany.com or contact the Brewer Customer Service Department at (1-888-Brewer1).
Figure 19. Fuse Removal
