Document #100578 RevJ 5 Printed in USA © 2017
*Classied in the United States and Canada per
the standards listed above.
NOTICE
Inspect Carton and Contents
Inspect all boxes and contents for
damage. Report any damage to the
carrier immediately.
No Sharp Tools
To avoid damaging the table’s
upholstery or painted surfaces, DO
NOT use a knife or other sharp object
to open the packaging.
NOTICE
Overview
Perform the following sequence in order when setting up
the table:
- Uncrating the Table
- Leveling the Table
- Installing the Paper Rod
Tools Required
- 1/2” socket wrench
- Pliers
1. Carefully remove outer carton by removing the staples along the bottom of the carton and lift off table.
2. Unbolt the table from the shipping pallet by removing the 4 bolt screws from the pallet with a 1/2” socket wrench
and remove the shipping bracket. See Figure 3.
Uncrating
Figure 3. Table Lift Points
Lift Points
Lift Point
(Push top rear drawer through to one
side, and use opening as a hand hold)
Bolt Screw
Shipping Bracket
INSTALLATION
Optimum Table Performance
For optimum table performance, allow the table to reach room
temperature before operating.
NOTICE
