OPERATION
Figure 6. Leg Support and Treatment Pan
Horizontal Positioning
Leg Support Pad
Treatment Pan
Leg Support
Leg Support
The leg support is located under the seat cushion
(Figure 6). It can be extended 15” for the patient prone
position. Pull leg support out to the desired position. The
leg support pad will extend along with the leg support. To
return the leg support to its stored position simply push
the leg support in.
Leg Support Pad
The leg support pad can be slid beneath the seat with
the leg support extended for easy access to the treat-
ment pan (Figure 6). Pushing the leg support back in will
allow the glides on the pad to drop into slots. The pad
will once again come out with the leg support the next
time it is pulled out.
Treatment Pan
A removable treatment pan is built-in underneath the
leg support pad for use during examinations (Figure 6).
Pull the leg support fully out and remove the leg support
pad or slide it back under the seat to access the pan.
Remove the treatment pan for cleaning.
Fall Hazard
The leg support is not intended for use as a
seat. Sitting on leg support could cause it to
retract, bend, or cause the table to tip forward,
creating a fall hazard leading to serious injury.
WARNING
Front Drawers
Storage drawers for supplies are located at the front
of the table (Figure 6). Model 5001 is equipped with
a drawer warmer located above the top drawer that
is turned on by a switch located above the drawer
(Figure 7).
Front Drawers
Figure 7. Heater On/Off Switch
Heater Switch
