Loading And Unloading The Trailer
Bri-Mar 92
Figure 5-2 – Release Latch Pin On Ramps
^ Caution
The weight of each loading ramp is 90 lbs.
Use a safe lifting procedure to prevent personal injury when handling
ramps.
• Remove ramps from storage position and place bracket (2) on ramps,
in channel on trailer. See figure 5-3. Position ramps as needed for
the width of the equipment to be loaded.
