ANCHORING AND TOWING. Strong points.
On the boat there is space to accommodate the anchor (Fig.D16).
1 - anchor storage compartment
2 - inner ring for fixing rope
3 - U-bolt for fixing the anchor / tow rope
4 - bow plate
5 - bow roller
6 - clam-bollard for rope 6-10mm
Equip your boat with an anchor of suitable size and type.
Fix the rope for anchoring / towing only for U-bolt (3).
Rope for anchoring / towing must be appropriate strength, diameter and
length.
1
3
4
5
2
6
Fig.D16
A tow line shall always be made fast in such a way that it can be released when under load.
Always tow or be towed at a slow speed. Never exceed the hull speed of a displacement
craft when being towed.
Always use a roller (5) and clam-bollard (6) to tighten the rope to avoid damage of the buoyancy tube.
Roller and clam-bollard are made of nylon and have a limited lifespan. Check them periodically for damage.
Replace them if necessary.
U-bolt (3) is designed for a maximum load of 14kN.
The breaking strength of rope shall in general not exceed 80 % of the breaking strength of the
respective strong point.
