BRIG Eagle 6 - How to Install Sundeck

— 29 —
EAGLE 6 2378G.01
Sundeck set includes two false deck boards and two soft cushions. In order to install the sundeck (Fig. A1), please do the next:
— Open front seat of the steering console (Fig. A1a).
— Put false deck boards into the special drops in the front wall of the cockpit and the front wall of the console, (Fig. A1b).
— Close the front seat of the steering console (Fig. A1c).
— Further, please place two soft cushions onto the false decks and fasten them with the help of press-buttons (Fig. A1d).
lHOW TO INSTALL SUNDECK.
A1
c
b
a
d
front seat of the steering console
false deck boards
Soft cushion
Always check fixation of the sundeck cushions.
Front locker removable cushions
